High Brightness Energy Saving Full Color Outdoor Fixed LED Display
for Advertising
The Outdoor SMD LED Display use state-of-art outdoor application
LEDs, the display brightness can be comparable with DIP oval LED
Display but with much wider viewing angle reach to 140 degree both
horizontal and vertical. The LEDs has the advantage of UV against.
Features of the outdoor SMD LED Display:
*Wide viewing angle: Horizontal 140degree, Vertical 140degree
*Weatherproof to IP65 standards
*UV against
*Easily configured for various size and aspect ratios
*Brightness from 5000 nits onwards
Functions :
1. High refresh rate: With NOVA STAR control system, no scanning
line when photographed
2. High gray level: 256 RGB each ,display 16.7M colors ,vivid and
perfect video effect
3. High resolution: The most apparent features of the new
generation of LED display
4. Good color uniformity: With brand Lamp Nationstar and high
refresh MBI5124 IC.
5. High Brightness: 6000-8000 cd/m2 ,brightness automatically
adjusted
6. High Quality: CE, RoHs, FCC, UL, IP65, ISO9001 passed + 96 Hours
serious testing time
7. Long life span: over100,000hours, warranty from 2 to 5 years.
Our advantage:
1. Full-color LED display is composed of RGB trichromatic leds, 36
bit color can be shown, and the real-time, synchronous display all
kinds of information, such as 2 d or 3 d animation, video,
television and live streaming video content.
2 .Screen after use for a long time still can keep perfect quality
and white balance and enough brightness.
3. LED optical design, high precision, the RGB tricolor LED the far
field of view perfect match, in order to make sure from any Angle
can be the perfect reappearance of video picture
4. High quality LED chips, anti static, high wavelength stability;
5. Advanced packaging equipment, guarantee the quality and life
expectancy;
6. Has a large Angle, color uniformity, low failure rate and easy
maintenance.
7. Standard processing technology to ensure that each row and each
column tube at the same level, ensure the stability of the clear
picture.
| Pixel Pitch: | 8mm |
| Pixel Density | 15625 pixels/m2 |
| Pixels Composition | 1R1G1B |
| LED Type | SMD3535 |
| Module Resolution (H x V) | 32x16 pixels |
| Module size (H x V) | 256mm L x 128mm H |
| Drive IC: | China brand |
| Driving method: | 1/4scan |
| Brightness: | >6000cd/m2 |
| Net Weight: | about 30kg/sqm |
| Cabinet size: | can be customized |
| Cabinet Resolution: | depend on the size |
| Cabinet Material: | Die-casting aluminium/iron |
| Maintenance: | back-door maintenance |
| Max. Power Consumption: | 800W |
| Average Power Consumption: | 350W |
| Ingression Protection Grade: | outdoor use,waterproof IP65 |
| Best Viewing Distance: | 8-80m |
| Optimal Viewing Angle: | H>140°, V>120° |
| LED Life Span: | 50,000 - 100,000 hrs |
| Operating Environment: | -20℃～+60℃; Humidity: 10% -90% |
| Inputting Voltage: | AC110V/220V ±10%, 50/60hz |
| Power Supply: | CL brand, 5V40A |
| Control System: | Synchronous |
| Grey Scale/Display Color: | 14bit / 16.7M |
| Refresh Rate: | ≥1920Hz/s |
| Systems Operating Platform: | XP, Windows7, Windows10 etc. |
| wooden box package: | 4 in 1 |
