    High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span

    Ask Lasest Price
    Brand Name : HANJING
    Model Number : P4mm
    Certification : CE/ROHS/FCC
    Price : Negotiation
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory,USD
    Supply Ability : 600 sets per month
    Delivery Time : 25-30 working days after received your payment
    • Product Details
    • Company Profile

    High Brightness P4mm Outdoor Advertising LED Display SMD2121 Panel Long Life Span

    Specifications:


    ModuleTechnical Parameters
    Pixel Pitch4mm
    LED TypeSMD2121
    Module Size (mm)320mm*160mm
    Module Resolution80dots*40dots
    Module weight0.23kg
    Brightness≤800 nit
    Refresh Rate≥1920 Hz
    Driving Method1/20scan
    Grey level16bits
    Color Display281 trillion
    IP GradeIP31
    Power consumption (Max/Average)600/200 W/sq.m
    LifeSpan100000 hour
    Cabinet
    Cabinet Size(WXH)640mm*640mm
    Cabinet resolution128*128 Pixeles
    Cabinet MaterialDie-cast Aluminum
    Cabinet weight(kg)8kg
    Pixel density25000 Pixeles /m²
    InstallationFlat Installation And Arc Installation
    Control systemFull color asynchronous /synchronous
    Data interconnectionWifi / USB / HDMI
    SoftwarePC software or Android App or IOS App
    Application environment
    Input AC power voltage110V-240V
    Working temperatureindoor:-20℃~50℃
    Working humidityhumidity:10%-90%RH
    Signal type(with video processor)AV, S-Video, VGA, DVI, HDMI, SDI, DP
    Control distanceHSYV: <100m; SMF: <10km

    Full Color Outdoor P4 LED Screen for advertising with high brightness, good uniformity, good stability and good waterproof


    Product Features:


    1. SMD led encapsulation technology confirm the wide view angle up to 140 degree for horizontal and vertical, and good uniformity,less than 0.1mm difference

    2. High quality leds with black body with high contrast,high brightness up to 6500nits

    3. Good Waterproof IP65, can be used under heavy rain weather and humid area

    4. Stability Iron cabinets for fixed installation, with fast lock and aviation plugs, conveninet to install and dismantle

    5. High quality, meet the request of international standard of CE, FCC,RoHs

    6. Long life span >100000hours, and 3 year warranty

    7, Vivid and exact picture, minimum noise, advanced test equipment, support any PC operation system and play a variety of information likevideo, word, flash, music, clock, graph etc.
    8, High brightness and support brightness automatically adjustment.
    9, Long lifespan, can reach more than 100, 000 hours, while the power consumption is lower than one tenth of lamp or neon;
    10, Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display system;
    11, Rich outdoor full color LED display screen engineering experience both in domestic and international market.
