Outdoor building large football stadium stadium perimeter P10 High
Brightness Outdoor Full Color Stadium LED Display
Application:
1. SMT led encapsulation confirm slim thickness and good uniformity
2. Good waterproof, IP65 grade, Anti-corrosion,Antifogging,Long
life span
3. High pixel density, Long view distance, High definition, Good
display vision
4. Good protection with soft mask and thick bongrace,avoid to be
broken and to hurt sportsmen
5. Widely used for commercial advertising, match live
broadcasting,sport rebroadcast, company logo, for fixed or for
rental use which can be easily installed and removed
6. Outdoor commercial advertising billboard, stage, banks, stock
exchange centers, theme park, airport, schools, government
agencies, exhibition, meeting rooms, cinemas, hotels, and a variety
of public facilities and etc.
Our service
1. Your inquiry related to our products or price will be replied in
24hrs
2. OEM&ODM, any your customized led display we can help you to
design and put into product
3. Top quality+Reasonable price+Responsible After
Service=Successful & Win
4. Chipshow can offer you LED stage display, LED outdoor video
wall, wedding LED display, stage LED electronic screen and led
large screen full color display.
Our advantages
1:Double Security Strong and Flat
IP65 for rear and back side, fit for naked installation without
decoration.
Dual backup for power supply and system,double security.
The surface is dark black, strong and flat, UV-resistancemodule
components,make the screen keep flat.
2: Support Format Low Cost Installation
Broadct color gamut, intelligent adjustment for color temperature
and brightness.Uniform color, high contrast, the picture is vivid
and nature.
Support main displaying format, workable for DVI HDMI 3G/HD/SD SDI
display format.
Modularized design,low cost for installation and maintenance, easy
to operate,support hot plugging.
stadium High Brightness Outdoor Full Color StadiumLED Display
Specifications:
| LED Chip |
| No. | LED constitution | Types |
| 1 | 1R1B1G | Epistar 3in1 SMD |
| 2 | Red wavelength (dominant) | 620~625 |
| 3 | Green wavelength (dominant) | 525~530 |
| 4 | Blue wavelength (dominant) | 470~475 |
| Module Specifications |
| 1 | Pixel Pitch | 10mm |
| 2 | Drive mode | constant current |
| 3 | Module Size | 320mm × 160mm |
| 4 | Module Resolution | H32dots × 16dots |
| 5 | Module Pixles | 512 dots |
| 6 | Driving Method | 1/2 scan |
| Cabinet / Frame Specification |
| 1 | Cabinet Size(WXH) | W 1280mm × H960mm X 168pcs |
| 2 | Cabinet Resolution | W128 dots × H 96dots |
| 3 | Module Quanity | 4pcs x 3pcs = 12pcs |
| 4 | Pixel Density | 10000 dots/m2 |
| 5 | Material | Epoxy paint coated cold steel box |
| 6 | Cabinet Weight | 55Kg /pcs |
| 7 | Mounting system | Fixed with 4pcs M10 bolts |
| 8 | Ingress protection (front/rear) | IP65/IP65 |
| 9 | Panel service access | Back service |
| Screen Parameters |
| 5 | Brightness | ≥75000cd / sq.m. |
| 6 | View Angle | Horizontal 120° Vertical 60° |
| 7 | Recommended best viewing distance | 10 meter ~ 200 meter |
| 8 | Input voltage (nominal) | 110 V.AC to 240V.AC |
| 9 | Input power frequency | 50 to 60 Hertz | |
| 10 | Input power (max) | 800 w/sq.m. |
| 11 | Input power (average) | 280 w/sq.m. |
| 12 | Screen weight | 45kg/sq.m. |
| 13 | Grey scale (linear) | 65,536 levels per color |
| 14 | Operating temperature range | ﹣30℃ to +60℃ |
| 15 | Humidity operating | 10% ~ 90% /RH |
| 16 | Colors | 281 Trillion |
| 17 | Contrast ratio | 1000:01:00 |
| 18 | Processing depth | 16 bit |
| 19 | Video frame rate | 60 Hertz |
| 20 | Display refresh rate | 900～3840 Hertz |
| 21 | Lifetime (50% brightness) | ≥100,000 Hours |
| 22 | Source compatibility (with video processor) | YC, VGA, DVI, YUV, SDI, CVBS,GD-SDI |
| 23 | Data interconnection | UTP Cat 5/Optical Fiber |
| 24 | Control system | Synchronous/asynchronous control system |
| |
