    IP65 Digital Speed Limit Signs , Electronic Speed Warning Signs Pitch 31.25mm

    Ask Lasest Price
    Brand Name : HANJING
    Model Number : electronic speed limit sign
    Certification : CE/ROHS/FCC/ETL/TUV
    Price : Negotiation
    Payment Terms : 35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
    Supply Ability : 1000 sets per month
    Delivery Time : 8-25 working days after received your payment
    • Product Details
    • Company Profile

    IP65 Digital Speed Limit Signs , Electronic Speed Warning Signs Pitch 31.25mm

    Feature:

    Pitch 31.25mm;
    Pixel config: 2R1G1B / 1R1G1B;
    Brightness:8000nit+;
    Cabinet protection: IP65/65;
    Front service;
    Tri-color/ Full Color;
    Remote control by Fiber optic or 4G;
    Communication protocal:TCP/IP;


    LED intelligent traffic screen mainly includes: traffic variable information signs, car information advertising screen, etc. The traffic variable information sign screen can be divided into variable information board, speed limit sign, traffic route display screen, lane indicator, fare screen and traffic signal light, etc

    Traffic variable information sign is mainly used for road traffic information release, road traffic penetration, road speed limit and toll station lane traffic instructions, fee information and road traffic signals


    Specifications:


    ModuleTechnical Parameters
    Pixel Pitch20mm
    LED TypeDIP LED
    Module Size (mm)size can be customized.
    Module Resolutioncustom-made
    Module weight45kg/ sq.m
    Brightness≤8000 nit
    Refresh Rate≥1920 Hz
    Driving MethodStatic scan
    Grey level16bits
    Color Display281 trillion
    IP GradeIP65
    Power consumption (Max/ biggest)700 W/sq.m
    Power consumption (Max/Average)240 W/sq.m
    LifeSpan100000 hour
    Cabinet
    Cabinet Size(WXH)size can be customized.
    Cabinet resolutionsize can be customized.
    Cabinet MaterialIron box technology
    Cabinet weight(kg)455kg/m²
    Pixel density1600Pixeles /m²
    InstallationFlat Installation And Arc Installation
    Control systemFull color asynchronous /synchronous
    Data interconnectionUTP Cat 5
    SoftwarePC software or Android App or IOS App
    Mounting systemFixed with M10 bolts
    Application environment
    Input AC power voltage110V-240V
    Working temperatureoudoor:-30℃~60℃
    Working humidityhumidity:10%-90%RH
    Signal type(with video processor)TCP / IP
    Control distanceHSYV: <100m; SMF: <10km
