P3.91 indoor LED display :
LED display use state-of-the-art 3 in 1 SMD. The display can show
colorful static and dynamic images vividly. With the advantages of
high resolution, high brightness, low power consumption, they are
perfect for indoor use to show high definition DVD, VCD, TV
programs and so on.
1, LED Density: 62500 pixel/sqm;
2, For indoor fixed installation application;
3, True and natural color, perfect displaying effect;
4, High brightness & high resolution;
5, Seamless panels with excellent flatness;
6,Wide viewing angle: 140 degree both horizontal and vertical;
7, High contrast ratio which ensures vivid images;
8,Low power consumption, environmentally friendly;
9, High contrast ratio which ensures vivid images;
10,Wide viewing angle: 140 degree both horizontal and vertical;
11,High color saturation, high contrast for good image display.
Specifications:
Module | Technical Parameters |
Pixel Pitch | 3.91mm |
LED Type | SMD2121 |
Module Size (mm) | 250mm*250mm |
Module Resolution | 64dots*64dots |
Module weight | 0.55kg |
Brightness | ≤1000 nit |
Refresh Rate | ≥1920 Hz |
Driving Method | 1/16 scan |
Grey level | 16bits |
Color Display | 281 trillion |
IP Grade | IP31 |
Power consumption (Max/Average) | 600/200 W/sq.m |
LifeSpan | 100000 hour |
Cabinet |
Cabinet Size(WXH) | 500mm*1000mm |
Cabinet resolution | 128*256 Pixeles |
Cabinet Material | Die-cast Aluminum |
Cabinet weight(kg) | 11kg |
Pixel density | 65536 Pixeles /m² |
Installation | Flat Installation And Arc Installation |
Control system | Full color asynchronous /synchronous |
Data interconnection | Wifi / USB / HDMI |
Software | PC software or Android App or IOS App |
Application environment |
Input AC power voltage | 110V-240V |
Working temperature | indoor:-20℃~50℃ |
Working humidity | humidity:10%-90%RH |
Signal type(with video processor) | AV, S-Video, VGA, DVI, HDMI, SDI, DP |
Control distance | HSYV: <100m; SMF: <10km |
